Dual Lenses for Wider and Smarter Indoor Protection

The EZVIZ TY7 Dual 4MP + 4MP Smart Home Camera is built for users who need more than a conventional single-lens indoor camera. Its dual-lens design combines:

• A 2K+ adjustable wide-angle lens for broader area monitoring
• A 2K+ motorized pan-and-tilt lens for flexible viewing and tracking

The two lenses can work independently or together, allowing the camera to monitor multiple areas while providing a closer view of important movement. This makes the TY7 Dual suitable for larger rooms, family homes, shops, offices, elderly monitoring, children, and pets.

---

Key Features

• 4MP + 4MP Dual-Lens Camera – Two 2K+ lenses provide detailed simultaneous monitoring.
• Dual-Lens Viewing – Monitor a wide area while keeping a closer view of important activity.
• 360° Panoramic Monitoring – The motorized lens provides extensive room coverage.
• Co-Detection for Auto Smart Tracking – One lens can detect movement while the pan-and-tilt lens follows the subject.
• AI-Powered Human Shape Detection – Helps identify human movement and reduce unnecessary alerts.
• Two Patrol Modes – Automatically scan the room or follow customized preset patrol points.
• Smart Color Night Vision – Capture useful color details in low-light conditions.
• IR Night Vision up to 10m – Continue monitoring in complete darkness.
• Loud Noise Detection – Detect sudden abnormal sounds such as crying or loud noises.
• Two-Way Calling with Touch Button – Communicate through the camera and allow family members to initiate a call.
• Dual-Band WiFi 6 – Supports both 2.4GHz and 5GHz wireless networks.
• Wired Ethernet Support – Includes RJ45 connectivity for a stable wired network option.
• microSD Storage up to 512GB – Store recordings locally.
• EZVIZ CloudPlay Support – Optional cloud storage where available.
• H.265 Video Compression – Reduces storage and bandwidth requirements.
• Sleep Mode for Privacy – Temporarily stop monitoring when privacy is needed.
• Smart Home Integration – Supports compatible Google Assistant and Amazon Alexa devices.
• Type-C Power Interface – Convenient modern power connection.

---

Dual 2K+ Lenses for Better Coverage

The TY7 Dual uses two 4MP / 2K+ lenses to provide more visual coverage than a conventional indoor camera. The lower adjustable wide-angle lens helps maintain a broad view of the room, while the upper pan-and-tilt lens can rotate to follow activity or inspect a specific area. This gives you both:

• The bigger picture
• A closer look at important details

from a single device.

---

Wide-Angle Lens

The adjustable wide-angle lens uses a 2.8mm F1.6 lens with approximately:

• 108° diagonal field of view
• 92° horizontal field of view
• 50° vertical field of view

It is ideal for keeping a constant view of key areas such as entrances, living spaces, counters, or hallways.

---

Pan & Tilt Lens

The motorized pan-and-tilt lens uses a 6mm F1.6 lens for a more focused viewing angle. It can rotate around the room to monitor activity and provide a closer perspective when needed. This allows the TY7 Dual to cover multiple areas while reducing blind spots.

---

Co-Detection for Auto Smart Tracking

One of the main advantages of the TY7 Dual is its ability to make both lenses work together. When the wide-angle lens detects a person entering its monitored area, the pan-and-tilt lens can automatically rotate toward the subject and continue following the movement. This helps the camera:

• Detect movement from a wider area
• Turn toward the detected person
• Follow movement automatically
• Capture additional detail
• Keep important activity within view

This is particularly useful in large rooms where movement may occur outside the initial direction of the motorized lens.

---

AI-Powered Human Shape Detection

The TY7 Dual uses AI-powered detection to identify human-shaped movement. This helps reduce unnecessary notifications caused by less important movements while keeping you informed when someone enters the monitored area. It is useful for monitoring:

• Family members
• Children
• Elderly parents
• Staff
• Customers
• Visitors
• Unexpected indoor activity

---

Two Patrol Modes for Automatic Monitoring

The TY7 Dual provides automated patrol options so you do not need to manually rotate the camera throughout the day.

Full Horizontal Patrol

The pan-and-tilt lens can automatically rotate across the room to check different areas.

Custom Patrol

You can create up to four preset positions and allow the camera to move between them at scheduled intervals. For example, you can monitor:

• Main entrance
• Living room
• Kitchen entrance
• Children’s play area

with one camera.

---

Smart Color Night Vision

The TY7 Dual is designed to continue monitoring after the lights go out. Its starlight imaging system and built-in spotlight support both traditional black-and-white night vision and smart color night vision. When Smart Color Night Vision is enabled, the camera can switch to color imaging when movement is detected. This helps preserve more useful visual details such as clothing colors and surrounding objects.

---

Infrared Night Vision up to 10m

For darker environments, the TY7 Dual supports infrared night vision at up to approximately 10 meters. This allows you to keep monitoring rooms even when there is little or no visible light.

---

Loud Noise Detection

The TY7 Dual can detect sudden changes in sound inside the monitored area. This can help notify you of situations such as:

• Baby crying
• Sudden shouting
• Loud impacts
• Unexpected noises
• Possible disturbances

This makes the camera useful for family monitoring in addition to standard indoor security.

---

Two-Way Calling with Touch Button

The camera features a built-in microphone and speaker for real-time two-way communication. A Touch Call Button on the camera allows someone near the device to initiate a call directly. This is especially useful for:

• Elderly family members
• Children
• Caregivers
• Family communication

Instead of needing to use a smartphone, the person near the camera can simply touch the button to reach you.

---

Dual-Band WiFi 6 Connectivity

The TY7 Dual supports modern WiFi 6 networking on both:

• 2.4GHz
• 5GHz

This provides greater flexibility when choosing the best wireless connection for your home or office. The camera also includes a 10M/100M RJ45 Ethernet port for users who prefer wired connectivity.

---

Flexible Local and Cloud Storage

The TY7 Dual supports two main recording options.

Local Storage

Insert a microSD card up to 512GB to store footage directly on the camera.

Cloud Storage

EZVIZ CloudPlay can be used for cloud-based recording where the service is available. microSD card is sold separately. Cloud storage availability and subscription requirements may vary by region.

---

H.265 Video Compression

The TY7 Dual supports H.265 video compression, helping reduce video file size and bandwidth consumption. This is particularly useful when recording from two high-resolution lenses. Compared with older H.264 technology, H.265 can help you store more footage using the same available storage capacity.

---

Sleep Mode for Privacy

For indoor environments, privacy can be just as important as monitoring. The TY7 Dual includes Sleep Mode, allowing users to temporarily disable monitoring when they do not want the camera active.

---

Smart Home Integration

The camera supports compatible smart home platforms including:

• Google Assistant
• Amazon Alexa

This allows compatible displays and voice assistants to access the camera feed using supported voice commands. Availability may vary depending on language, country, and compatible device.

---

Ideal For

The EZVIZ TY7 Dual is suitable for:

• Homes
• Apartments
• Living Rooms
• Large Indoor Areas
• Family Monitoring
• Baby Monitoring
• Elderly Monitoring
• Pet Monitoring
• Small Shops
• Retail Counters
• Offices
• Indoor Business Premises

It is particularly useful for users who want two viewing angles from one smart indoor camera.

---

Technical Specifications

---

What’s in the Box

• EZVIZ TY7 Dual Camera
• Power Adapter
• Power Cable
• Drill Template
• Mounting Plate
• Screw Kit
• Regulatory Information
• Quick Start Guide

---

Why Choose EZVIZ TY7 Dual?

The EZVIZ TY7 Dual 4MP + 4MP Dual-Lens Pan & Tilt WiFi 6 Camera provides a more flexible approach to indoor monitoring by combining two high-resolution lenses in one device. With dual 2K+ viewing, AI Human Detection, Co-Detection Auto Smart Tracking, Two Patrol Modes, Smart Color Night Vision, Loud Noise Detection, Two-Way Calling with Touch Button, WiFi 6, and up to 512GB local storage, it is designed for users who want wider coverage without installing multiple cameras. Two lenses. Wider coverage. Smarter indoor monitoring. [Download product datasheet]
