Clear Full HD Surveillance for Indoor Security
The
Hikvision DS-2CE76D0T-EXIPF 2MP Turret Camera is designed for dependable indoor video surveillance with clear day and night performance.
Its
2MP CMOS image sensor captures video at
1920 × 1080 resolution, providing sharp Full HD footage for everyday monitoring. The compact turret-style design makes it suitable for ceiling or wall installations in areas where a neat and discreet CCTV setup is preferred.
Key Features
- 2MP Full HD Imaging – Records at 1920 × 1080 resolution for clear everyday surveillance.
- 2MP CMOS Image Sensor – Provides reliable image quality for indoor monitoring.
- Up to 20m IR Night Vision – Maintains visibility in low-light and dark environments.
- Smart IR – Helps reduce excessive infrared exposure when subjects move closer to the camera.
- Digital WDR – Improves image visibility in scenes with strong lighting differences.
- 2D Digital Noise Reduction – Helps minimise image noise for cleaner video.
- 2.8mm or 3.6mm Fixed Lens – Choose the viewing angle that best suits the monitoring area.
- 4-in-1 Video Output – Supports switchable TVI, AHD, CVI, and CVBS signals.
- Flexible 3-Axis Adjustment – Allows easy positioning after installation.
- Indoor Turret Design – Compact form factor for homes, offices, shops, and indoor commercial areas.
- Hikvision-C Communication – Supports compatible up-the-coax control through Hikvision TVI systems.
- Low Power Consumption – Maximum power consumption of approximately 3.3W.
Full HD 1080p Video
The DS-2CE76D0T-EXIPF captures footage at
1920 × 1080 resolution, providing enough detail for common indoor surveillance needs.
It is well suited for monitoring:
- Living rooms
- Hallways
- Offices
- Retail stores
- Reception areas
- Indoor entrances
- Small warehouses
- Commercial spaces
Up to 20m Infrared Night Vision
The camera is equipped with infrared illumination capable of reaching up to
20 metres, helping maintain visibility when surrounding light levels drop.
This makes it suitable for locations that need dependable monitoring after business hours or during the night.
Smart IR for Better Night Imaging
Bright infrared light can sometimes overexpose nearby faces or objects.
The camera’s
Smart IR feature helps manage IR intensity, improving image balance when subjects move closer to the lens.
Digital WDR for Difficult Lighting
The built-in
Digital Wide Dynamic Range helps improve visibility when bright and dark areas appear in the same scene.
This is useful in locations such as entrances, corridors, and indoor spaces with windows or strong backlighting.
2D Digital Noise Reduction
The camera supports
2D DNR, which helps reduce image noise and improve overall clarity, particularly in lower-light environments.
Flexible 4-in-1 Video Output
The Hikvision DS-2CE76D0T-EXIPF supports four video signal formats from one camera:
This provides greater flexibility when integrating the camera with different analogue DVR systems.
Lens Options
2.8mm Fixed Lens
Provides a wider field of view with approximately:
- 102° horizontal
- 55° vertical
- 123° diagonal
This option is suitable for wider rooms and general area monitoring.
3.6mm Fixed Lens
Provides a slightly narrower view with approximately:
- 81° horizontal
- 42° vertical
- 100° diagonal
This option is useful when a more focused view is required.
Flexible Camera Positioning
The camera allows wide physical adjustment after mounting:
- Pan: 0° to 360°
- Tilt: 0° to 75°
- Rotation: 0° to 360°
This makes it easier to fine-tune the viewing direction during installation.
Ideal For
The Hikvision DS-2CE76D0T-EXIPF is suitable for:
- Residential indoor CCTV
- Offices
- Retail shops
- Reception areas
- Hallways
- Indoor entrances
- Small businesses
- Storerooms
- Indoor commercial premises
Technical Specifications
| Specification |
Details |
| Model |
Hikvision DS-2CE76D0T-EXIPF |
| Camera Type |
2MP Indoor EXIR Fixed Turret Camera |
| Image Sensor |
2MP CMOS |
| Signal System |
PAL / NTSC |
| Maximum Resolution |
1920 × 1080 |
| TVI Frame Rate |
1080p @ 25fps / 30fps |
| AHD Frame Rate |
1080p @ 25fps / 30fps |
| CVI Frame Rate |
1080p @ 25fps / 30fps |
| CVBS |
PAL / NTSC |
| Minimum Illumination |
0.02 Lux @ F1.2, AGC On; 0 Lux with IR |
| Lens Options |
2.8mm / 3.6mm Fixed Lens |
| 2.8mm FOV |
102° H / 55° V / 123° D |
| 3.6mm FOV |
81° H / 42° V / 100° D |
| Lens Mount |
M12 |
| Day & Night |
ICR |
| WDR |
Digital WDR |
| Image Mode |
STD / HIGH-SAT |
| AGC |
Yes |
| Day/Night Mode |
Auto / Color / B&W |
| White Balance |
Auto |
| Exposure Modes |
DWDR / BLC / Global |
| Noise Reduction |
2D DNR |
| Image Functions |
Brightness, Mirror, Smart IR, Sharpness |
| Video Output |
Switchable TVI / AHD / CVI / CVBS |
| IR Range |
Up to 20m |
| Angle Adjustment |
Pan 0°–360°, Tilt 0°–75°, Rotation 0°–360° |
| Communication |
Hikvision-C |
| Operating Temperature |
-40°C to 60°C |
| Operating Humidity |
90% or less, non-condensing |
| Power Supply |
12V DC ±25% |
| Maximum Power Consumption |
3.3W |
| Housing Material |
Plastic |
| Dimensions |
Ø84.6 × 78.9 mm |
| Weight |
Approx. 195g |
Why Choose the Hikvision DS-2CE76D0T-EXIPF?
The
Hikvision DS-2CE76D0T-EXIPF 2MP Turret Camera offers a simple and flexible solution for indoor analogue CCTV systems.
With
1080p Full HD resolution, up to 20m IR night vision, Smart IR, Digital WDR, 2D DNR, and switchable TVI/AHD/CVI/CVBS output, it is a practical option for both new installations and upgrades to existing analogue surveillance systems.
Clear 1080p monitoring. Reliable night vision. Flexible system compatibility.
[
